Rumah > Produk> Detektor Gas Tunggal> Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring

Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring

Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring
Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring
Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof with 0-2000ppm Measure Range for Industrial H2 Leak Monitoring
Informasi Dasar
Tempat asal: CINA
Nama merek: SAFEGAS
Sertifikasi: ATEX/EMC/IECEX
Nomor model: Minimeta
Kuantitas min Order: 1
Harga: dapat dinegosiasikan
Kemasan rincian: Karton
Waktu pengiriman: 3 hari kerja
Syarat-syarat pembayaran: T/T, Western Union
Menyediakan kemampuan: 3000 Potongan Per Bulan
Harga terbaik Hubungi sekarang
Informasi Detail
Gas terdeteksi: H2 Prinsip Deteksi: Difusi
Rentang ukuran: 0-1000ppm/2000ppm Resolusi: 1ppm
Ketepatan: ≤ ± 2-5%FS Waktu respons (T90): 15 hingga 30 tahun
Prinsip: Prinsip elektrokimia Menampilkan: Nama gas, daya baterai, unit konsentrasi, nilai terukur
Mode alarm: Alarm suara, cahaya, getaran Jenis Alarm: Alarm rendah, alarm tinggi, STEL, TWA, kalibrasi opsional baterai lemah dan uji benturan
Mode Catu Daya:: Baterai kering 3,6V (tidak dapat diisi ulang dan dapat diganti) Sertifikasi anti-ledakan: Iecex, atex
Kelas Perlindungan: IP66/68 Suhu Kerja: -20 ℃ hingga 55 ℃
Kelembaban kerja (non-condensing): 0-95% RH Tekanan Udara Kerja: 86 hingga 106kpa
Ukuran: 90mm*60mm*33mm (panjang*lebar*tebal) Berat (Dengan Klip): 125 gram

Deskripsi Produk

Portable Electrochemical Hydrogen Gas Detector IP68 Waterproof Industrial H2 Leak Monitor
Product Overview

Minimeta Portable H2 Gas Detector is a high-precision portable gas detector for hydrogen detection using diffusion detection principle, designed for industrial safety applications.

MiniMeta is an IECEX/ATEX/EMC certified single-gas detector that can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection. Designed to offer a low-cost, long-term ownership gas monitoring system.

Key Features
  • IP68 water- and dust-resistant case
  • Low power consumption with 2 years standby time - no battery charging or calibration needed
  • Optional single/multi unit docking station for daily bump test and calibration
  • Event and data logging function
  • Self-test function for improved safety through automatic self-testing
  • Small size, lightweight design with back clip for easy carrying
  • 95db@30cm buzzer alarm, 2 high-bright red LED light alarm and vibration alarm
  • Real time value, TWA, STEL, MAX, MIN multiple numerical display
Portable Hydrogen Gas Detector front view Portable Hydrogen Gas Detector side view Portable Hydrogen Gas Detector display close-up Portable Hydrogen Gas Detector back view with clip Portable Hydrogen Gas Detector in use scenario
Technical Parameters
ParameterSpecification
Detect gasH2
Sensor typeElectrochemical
Sampling methodDiffusion
Measure range0-2000PPM
Resolution0.1ppm
Precision≤± 3% F.S.
Response Time≤30s(T90)
UnitPPM
DisplayGas name, concentration unit, measured value, electricity
Alarm modeSound, light, vibration alarm, high and low alarm values can be set by user
Alarm typeLow alarm, high alarm, STEL, TWA, low battery
DisplayLCD Display
Operating languageChinese/English
Size90*60*33mm
Weight125g
Working Temperature-20ºC~50ºC
Working Humidity0-95%RH
Working air pressure86~106kpa
Company Advantages
  • R&D team experience: over 25 years
  • Company certifications: ISO9001, ISO45001
  • Product certifications: IECEx, ATEX, CE
  • Delivery time: 5-7 days
  • Annual capacity: 80,000 units
  • Professional 7*24 hours customer service
Manufacturer Profile

Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.

Product Line

Our product portfolio includes portable detectors, fixed systems, controller panels and particle counters:

  • Portable: Minimeta, Micmeta, YT-1200H-S, SKY3000, SKY2000, SKY8000, SKY1000, MAXMETA
  • Fixed: YT-95H, YT-98H, YT-96H, SG100, SG200
  • Controllers: YT-1100H, YT-1600H, YT-1800H
  • Particle Counter: AQD5000, SKY6000-PM, SKY2000-PM
Gas detection product line overview Industrial gas detection systems Gas detection controller units
